Brass Short Shank Type Fitting, 0.25 Inch Hose ID to 7/16-20 SAE 45 deg Flare, Straight

C
1.25
E
0.97
Brand
Dixon Valve & Co
Brand
Dixon Valve & Co
Pack Size
1.00
UOM
EA
Finish
No
Hose I.D.
0.25
Supplier Part Number
1430407K
Alternate Part Numbers
Alternate Part Number C1FS72, Alternate Part Number MI-00361881, Alternate Part Number MINO-00056F96286
Product Weight
0.04 lbs

Product Questions & Answers

fitting's made of brass right? trying to figure out if it'll hold up running hydraulic fluid through it for suction and discharge on a low pressure setup
Question by: Hank G on Dec 15, 2025, 2:00 PM
Brass is exactly what you've got here. Machined from free cutting brass rod, CDA 360 alloy specifically, so it's a solid material choice for low pressure fluid transfer including suction and discharge lines. Just keep in mind the working pressure you can expect out of it will depend on the hose itself, the clamps you're using, how many clamps are on there, placement, and what fluid you're running through it. The fitting doesn't carry a fixed pressure rating independent of those factors.
Answer by: Customer Support on Dec 16, 2025, 9:34 PM

Similar Products

Model Number Finish Hose I.D. Thread 1 C E Price Buy Now
143-0407 No 0.25 7/16-20 1.25 0.97
143-0408 No 0.25 1/2-20 1.31 0.97
143-0508 No 0.313 1/2-20 1.31 0.97
143-0612 No 0.375 3/4-16 1.34 0.97
143-0812 No 0.5 3/4-16 1.34 0.97
143-0814 No 0.5 7/8-14 1.34 0.97
144-0410 No 0.25 5/8-18 1.27 0.97
144-0510 No 0.313 5/8-18 1.27 0.97
144-0610 No 0.375 5/8-18 1.27 0.97
