304SS 2.5" 0-1,500 PSI/ 0-100 Bar Liquid Filled Pressure Gauge, 1/4 NPT Bottom Connection

Ask A Question
Calibrated
No
Case Included
No
Dimensions
A=2.48 B=1.21 C=2.71 D=0.46
Brand
Engineered Specialty Products – Esp
Brand
Engineered Specialty Products
Pack Size
1.00
UOM
EA
Fill Type
Liquid Filled
Materials
304SS
Specifications
2.5" 0-1,500 PSI/ 0-100 Bar
Supplier Part Number
PRO-201L-254N
Thread 1
1/4 NPT
Alternate Part Numbers
Alternate Part Number 209972-ASHCROFT, Alternate Part Number 574308, Alternate Part Number 631008AL02L1500, Alternate Part Number 638008A4G02LP0LBR15002421, Alternate Part Number 638008A4G02LP0LBR150024214, Alternate Part Number 649102, Alternate Part Number 7211-2-1/2-1/4-1500, Alternate Part Number C1KA76, Alternate Part Number C1ND95
Product Weight
0.99 lbs
Product Questions & Answers 2

Product Questions & Answers

got a line that bounces around some, is this gauge gonna hold steady or is it touchy?
Question by: Marvin E on Oct 12, 2025, 2:18 PM
Liquid fill helps a lot with that kind of service since it dampens vibration and shock so the needle is easier to read. It also has a 0.013 inch throttle plug in the 1/4 NPT bottom brass connection, which further smooths out pressure pulses for more stable readings.
Answer by: Customer Support on Oct 14, 2025, 7:39 AM
Wondering if this gauge can handle the pressure if it's always running near the top end of its range?
Question by: Jerry P on Jun 30, 2025, 8:25 AM
The recommendation is to keep normal operating pressure between 25% and 75% of the full scale. If you've got pulsation, you shouldn't exceed 50% of the full scale to keep the gauge working right.
Answer by: Customer Support on Jul 1, 2025, 5:57 PM

Similar Products

Part Number Model Number Specifications Fill Type Thread 1 Materials Dimensions Price Buy Now
PRO-201L-254U PRO-201L-254U 2.5" 0-10,000 PSI/ 0-700 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
465866 465866 2.5" 0-3,000 PSI/ 0-210 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254B 63 1008AL 02L 15#-9815 2.5" 0-15 PSI / 0-1.0 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254F 63 1008AL 02L 160#-9821 2.5" 0-160 PSI/ 0-11 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254H PRO-201L-254H 2.5" 0-300 PSI/ 0-20 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254A PRO-201L-254A 2.5" 0 - 30Hg/ 0- -1.0 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254CC PRO-201L-254CC 2.5" 30Hg-30 PSI/ -1.0-2.0 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254M PRO-201L-254M 2.5" 0-1,000 PSI/ 0-70 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
649027 649027 2.5" 0-100 PSI/ 0-7 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254O 63 1008AL 02L 2000#-9827 2.5" 0-2,000 PSI/ 0-140 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254CB 63 1008AL 02L 15#/V-9816 2.5" 30Hg-15 PSI/ -1.0 - 1.0 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254Q PRO-201L-254Q 2.5" 0-4,000 PSI/ 0-280 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
649140 649140 2.5" 0-5,000 PSI/ 0-350 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254V 63 1008AL 02L 15000#-9833 2.5" 0-15,000 PSI/ 0-1000 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
649065 649065 2.5" 0-200 PSI/ 0-14 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
648990 63 1008AL 02L 30#-9817 2.5" 0-30 PSI/ 0-2.0 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
649010 63 1008AL 02L 60#-9819 2.5" 0-60 PSI/ 0-4.0 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254P PRO-201L-254P 2.5" 0-3,000 PSI/ 0-210 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254K 63 1008AL 02L 600#-9824 2.5" 0-600 PSI/ 0-40 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254N 63 1008AL 02L 1500#-9826 2.5" 0-1,500 PSI/ 0-100 Bar Liquid Filled 1/4 NPT 304SS A=2.48 B=1.21 C=2.71 D=0.46
