AQP Wire Inserted Suction SAE 100R4 Blue Hose, 2.00 Inch ID, Up To 100.00 PSI

Abrasion Resistance 29	Application Suction application for hydraulic, lubrication oils, gasoline, air, water and chemical transfer.	Color Blue	Conductivity 30	Construction 2-ply braid	Cover Material Elastomer	Dash Size -32	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Hose I.D. 2	Hose O.D. 2.55	Impulse Cycle Life 500000 cycle	Lay Line Style Embossed	Maximum Operating Pressure 100	Minimum Bend Radius 12	Minimum Bend Radius 12	Minimum Working Temperature -40	Reel Qty (ft) Rolls Only	Reinforcement Material Helical Wire and Textile	Supplier Part Number 2661-32	Tube Material Synthetic Rubber	Vacuum Service 28	Alternate Part Numbers Alternate Part Number C1BJ24	Product Weight 4.48 lbs

Product Questions & Answers 2

Product Questions & Answers

got a 2 inch suction line on a hydraulic reservoir, is this hose the right kind for that or is it more for pressure?

Question by: Warren W on Jul 12, 2025, 1:54 PM

For a suction setup, it fits the job. It is an SAE 100R4 wire inserted suction hose with a 2.00 inch inside diameter, and it is rated up to 100 PSI max operating pressure. The reinforcement includes a helical wire between two textile braids, which is what helps it hold shape on suction.

Answer by: Customer Support on Jul 14, 2025, 6:20 AM

What kind of stuff can I use this hose for? I need it for suction.

Question by: Stan B on Apr 21, 2025, 9:21 AM

This Aeroquip hose is designed for suction applications involving hydraulic and lubrication oils, gasoline, air, water, and some chemical transfers.

Answer by: Customer Support on Apr 23, 2025, 7:33 AM

Similar Products

Model Number	Hose I.D.	Hose O.D.	Maximum Operating Pressure	Minimum Bend Radius	Vacuum Service	Reel Qty (ft)
2661-20	1.25	1.8	200	8	28	Rolls Only
2661-16	1	1.5	250	6	28	Rolls Only
2661-24	1.5	2.06	150	10	28	Rolls Only
2661-32	2	2.55	100	12	28	Rolls Only
2661-12	0.75	1.25	300	5	28	Rolls Only
