AQP Engine & Air Brake Blue Hose, FMVSS106, 1.13 Inch ID, Up to 300.00 PSI

Color Blue	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Hose I.D. 1.13	Hose O.D. 1.52	Maximum Operating Pressure 300	Minimum Bend Radius 4.50	Minimum Bend Radius 4.5	Reel Qty (ft) Rolls Only	Supplier Part Number FC355-20	Alternate Part Numbers Alternate Part Number C1EQ12	Product Weight 1.73 lbs

Product Questions & Answers 4

Product Questions & Answers

got an air brake line setup, is this hose actually rated for that and what’s it made of?

Question by: Gene M on Jul 7, 2025, 8:24 PM

For engine and air brake service, this hose is built with an AQP elastomer tube, a polyester inner braid, and a single wire braid reinforcement, finished with a blue AQP elastomer cover. It also calls out FMVSS106, which lines up with air brake hose requirements.

Answer by: Customer Support on Jul 9, 2025, 6:22 AM

got a compressor setup running pretty hot air. what is the max pressure on that if im just pumping air through it

Question by: Debbie W on Mar 29, 2025, 6:47 AM

Running air through the hose drops the maximum limits down to 250 PSI and 250 degrees Fahrenheit. For liquids like coolants or oils the rating goes up to the standard 300 PSI and 300 degrees.

Answer by: Customer Support on Mar 31, 2025, 6:48 AM

got a tight spot by the engine, how sharp can i bend this hose without kinkin it

Question by: Brett W on May 17, 2025, 9:23 AM

For routing, the minimum bend radius is 4.5 inches. Keeping bends at or above that radius helps it hold its shape and protects the reinforcement.

Answer by: Customer Support on May 19, 2025, 6:00 AM

What size is this hose, inside diameter-wise?

Question by: Judy W on Jan 23, 2026, 8:34 AM

It has an inner diameter of 1.13 inches.

Answer by: Customer Support on Jan 24, 2026, 10:44 AM

Similar Products

Model Number	Hose I.D.	Hose O.D.	Maximum Operating Pressure	Minimum Bend Radius	Vacuum Service	Reel Qty (ft)
FC355-16	0.88	1.24	400	3.5	15	Rolls Only
FC355-20	1.13	1.52	300	4.5	15	Rolls Only
FC355-04	0.19	0.52	1500	0.75	28	510-670
FC355-06				1.25
FC355-24	1.38	1.75	250	5.5	11	Rolls Only
