AQP Engine & Air Brake Blue Hose, FMVSS106, 0.88 Inch ID, Up to 400.00 PSI

Color
Blue
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
12.00
UOM
FT
Hose I.D.
0.88
Hose O.D.
1.24
Maximum Operating Pressure
400
Minimum Bend Radius
3.50
Minimum Bend Radius
3.5
Reel Qty (ft)
Rolls Only
Supplier Part Number
FC355-16
Alternate Part Numbers
Alternate Part Number C1HE59
Product Weight
1.39 lbs

Product Questions & Answers

gonna use this for a compressed air setup on my rig. what is the hottest temp it handles before giving out
Question by: Bobby S on Mar 15, 2026, 10:30 AM
Air applications max out at 250 degrees Fahrenheit. While the hose generally handles fluids up to 300 degrees, you need to keep compressed air under that 250-degree limit and below 250 PSI for safe operation.
Answer by: Customer Support on Mar 17, 2026, 10:25 AM
what's the max pressure this hose can handle for air brake use, and is that the same across all fluids or does it vary?
Question by: Danny W on Oct 20, 2025, 3:23 PM
For air service specifically, the limit is 250 PSI, not the full 400. The 400 PSI maximum operating pressure applies to other compatible fluids like fuel, lubricating oils, and coolants. So if you're running this in an air brake system, keep your operating pressure under that 250 PSI threshold. Temperature follows the same split logic too. Air should stay at or below 250 degrees F, while the overall hose rating goes up to 300 degrees F.
Answer by: Customer Support on Oct 22, 2025, 6:47 AM
got a tight spot on a truck frame, how sharp can i bend this blue air brake hose without kinkin it
Question by: Dustin P on Mar 14, 2026, 7:28 PM
For routing, the minimum bend radius is 3.5 inches. Keeping bends at or above that radius helps it stay flexible without collapsing or kinking.
Answer by: Customer Support on Mar 16, 2026, 1:45 PM

Similar Products

Model Number Hose I.D. Hose O.D. Maximum Operating Pressure Burst Pressure Minimum Bend Radius Vacuum Service Reel Qty (ft) Price Buy Now
FC355-16 0.88 1.24 400 3.5 15 Rolls Only
FC355-20 1.13 1.52 300 4.5 15 Rolls Only
FC355-04 0.19 0.52 1500 0.75 28 510-670
FC355-06 1.25
FC355-24 1.38 1.75 250 5.5 11 Rolls Only
