AQP Engine & Air Brake Blue Hose, FMVSS106, 0.19 Inch ID, Up to 1500.00 PSI

Color Blue	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Hose I.D. 0.19	Hose O.D. 0.52	Maximum Operating Pressure 1500	Minimum Bend Radius 0.75	Minimum Bend Radius 0.75	Reel Qty (ft) 510-670	Supplier Part Number FC355-04RL	Alternate Part Numbers Alternate Part Number C1EQ11, Alternate Part Number FC355-04RL, Alternate Part Number MI-03640827, Alternate Part Number MINO-00015F34695	Product Weight 0.62 lbs

Product Questions & Answers 4

Product Questions & Answers

Can this hose handle regular gasoline alright?

Question by: Carl C on Aug 9, 2025, 8:40 AM

Yes, this AQP engine and air brake hose is suitable for gasoline, along with air, fuel, lubricating oils, and coolants.

Answer by: Customer Support on Aug 10, 2025, 6:50 PM

got a tight spot to route this hose, how sharp can i bend it without kinking?

Question by: Cheryl S on Aug 19, 2025, 7:22 PM

For tight routing, the minimum bend radius on this hose is 0.75 inch. Keeping your bend at or above that radius helps avoid kinks and protects the reinforcement.

Answer by: Customer Support on Aug 21, 2025, 6:51 AM

What kind of fluids can this hose handle without breaking down?

Question by: Kirk K on May 3, 2025, 9:49 PM

This hose is compatible with air, gasoline, fuel, lubricating oils, and coolants.

Answer by: Customer Support on May 5, 2025, 6:39 AM

hose says it works for air brakes and engine stuff, but can it handle gasoline and oil lines too or is that pushing it?

Question by: Scott H on Oct 27, 2025, 10:25 AM

Fuel, lubricating oils, and coolants are all listed as compatible media for this hose, so running it on a gasoline or oil line is well within what it's built for. The AQP elastomer tube handles that range of fluids without issue, and the single wire braid reinforcement keeps it solid up to 1500 PSI. It's not a stretch to use it across multiple fluid types in the same application if needed.

Answer by: Customer Support on Oct 28, 2025, 1:18 PM

Similar Products

Model Number	Hose I.D.	Hose O.D.	Maximum Operating Pressure	Minimum Bend Radius	Vacuum Service	Reel Qty (ft)
FC355-16	0.88	1.24	400	3.5	15	Rolls Only
FC355-20	1.13	1.52	300	4.5	15	Rolls Only
FC355-04	0.19	0.52	1500	0.75	28	510-670
FC355-06				1.25
FC355-24	1.38	1.75	250	5.5	11	Rolls Only
