AN Style Urethane Wiper Ring, 0.62 Inch Rod Diameter, 0.89 Inch Groove OD, Inch Groove Width

Brand Hercules Sealing Products	Brand Hercules Sealing Products	Pack Size 1.00	UOM EA	Groove O.D. B 0.89	Rod Diameter A 0.62	Supplier Part Number AN-03	Product Weight 0.01 lbs	Alternate Part Numbers Alternate Part Number C1CH87, Alternate Part Number MI-00869397, Alternate Part Number MINO-00407X10045

Product Questions & Answers 3

Product Questions & Answers

Does this wiper ring fit a 0.62 inch rod, or is that just the nominal size? Want to make sure before I order.

Question by: Ronnie A on Apr 4, 2025, 3:49 PM

The rod diameter for this ring is 0.623 inches, so it's right at 0.62 inch nominal. The groove outside diameter comes in at 0.885 inches. As long as your cylinder matches those dimensions, you're looking at the right part.

Answer by: Customer Support on Apr 6, 2025, 6:33 AM

I need a wiper ring for a cylinder with a 0.62 inch rod. Will this one fit?

Question by: Rusty C on Sep 16, 2025, 4:39 PM

This AN style urethane wiper ring is designed for rods with a 0.623 inch diameter, so it should be a good fit for your cylinder.

Answer by: Customer Support on Sep 18, 2025, 1:40 PM

got a cylinder rod that measures right about 0.623, is this the right wiper size for that?

Question by: Diane C on Aug 4, 2025, 11:52 AM

The key callout is rod diameter A at 0.623 inch, so it matches a rod right around 0.62 inch. The groove OD (B) is 0.885 inch, so the housing groove also needs to be sized to that OD for the wiper to seat correctly.

Answer by: Customer Support on Aug 5, 2025, 9:38 PM

Similar Products

Model Number	Rod Diameter A	Groove O.D. B
AN-03	0.623	0.885
AN-09	0.998	1.272
AN-13	1.248	1.522
AN-21	1.998	2.302
AN-25	2.498	2.802
AN-02	0.56	0.823
AN-04	0.685	0.948
AN-05	0.748	1.01
AN-07	0.873	1.147
AN-08	0.935	1.209
AN-11	1.123	1.397
AN-12	1.185	1.459
AN-15	1.373	1.677
AN-16	1.435	1.739
AN-17	1.498	1.802
AN-18	1.623	1.927
AN-19	1.748	2.052
AN-20	1.873	2.177
AN-22	2.123	2.427
AN-23	2.248	2.552
AN-24	2.373	2.677
AN-26	2.623	2.989
AN-29	2.997	3.364
AN-31	3.247	3.614
AN-33	3.497	3.864
AN-35	3.747	4.114
AN-37	3.997	4.427
AN-41	4.497	4.927
AN-45	4.997	5.427
AN-49	5.497	5.927
