Bspp Test Port X 1/8" Bspp 9015TP-16-16-B02

Specifications

CH1 Width 41mm	CH2 Width 41mm	L Length 64.4mm	Adaptall Material Steel	Adaptall Shape Tee	Side 1 Callout G 1 - 11	Side 1 Gender M	Side 1 Size 1"	Side 1 Type Bspp	Side 2 Callout G 1 - 11	Side 2 Gender F	Side 2 Size 1"	Side 2 Type Bspp	Side 3 Callout G 1/8 - 28	Side 3 Gender F	Side 3 Size 1/8"	Side 3 Type BSPP	Brand Adaptall America	Brand Adaptall	Pack Size 1.00	UOM EA	Supplier Part Number 9015TP-16-16-B02	Product Weight 0.73 lbs

Product Questions & Answers 3

Product Questions & Answers

got a 1 inch BSPP line and want to add a gauge point, is this the tee that does that?

Question by: Merle W on Apr 2, 2026, 1:53 PM

For adding a test point in-line, this tee gives you a 1 inch BSPP male on Side 1, a 1 inch BSPP female on Side 2, and a 1/8 inch BSPP female test port on Side 3 (G 1/8 - 28). It’s meant for hydraulic testing and diagnostics where you need a small port for monitoring.

Answer by: Customer Support on Apr 4, 2026, 6:55 AM

What's the width on this test port? Just wanna make sure it'll fit where I need it.

Question by: Rex H on Dec 27, 2025, 6:07 PM

The width of this Adaptall BSPP test port is 41mm on both Channel 1 and Channel 2.

Answer by: Customer Support on Dec 29, 2025, 6:41 AM

what's the thread setup on this thing? trying to figure out if it'll tie into my existing 1" BSPP lines without a bunch of extra fittings

Question by: Steve A on Oct 12, 2025, 8:30 PM

Side 1 is a 1" BSPP male connection, and Side 2 is a 1" BSPP female, so it runs inline with your existing 1" BSPP hydraulic connections no problem. Side 3 is the test port itself, which is a 1/8" BSPP female. That's where you'd attach a pressure gauge or diagnostic instrument for monitoring. The tee shape keeps everything in line while giving you that dedicated tap point for testing.

Answer by: Customer Support on Oct 14, 2025, 6:25 AM
