Adaptall 90*Male Orfs X Mmetric Adj Elb 1522867

Specifications

Adaptall Material Steel	Adaptall Shape 90° Elbow	Side 1 Callout 11/16 - 16 UN	Side 1 Gender M	Side 1 Size 3/8"	Side 1 Type Orfs	Side 2 Callout M18 X 1.5	Side 2 Gender M	Side 2 Size 18mm	Side 2 Type Metric	Brand Adaptall America	Brand Adaptall	Pack Size 1.00	UOM EA	Supplier Part Number 6069-06-18	Product Weight 0.28 lbs

Product Questions & Answers 3

Product Questions & Answers

trying to hook an ORFS line to a metric port with a 90, is this the right elbow or am i off a size?

Question by: Dwight H on Apr 1, 2026, 6:16 PM

For the ORFS side, you are looking at a male 3/8 inch ORFS with an 11/16-16 UN thread callout. The other end is a male metric adjustable in 18 mm with an M18 x 1.5 callout. If those match what you have on each side, it is the right 90 degree adapter to bridge ORFS to metric.

Answer by: Customer Support on Apr 3, 2026, 6:18 AM

Will this fitting work to connect a ORFS to a metric system at a 90 degree angle?

Question by: Lance A on Jan 19, 2026, 7:20 AM

Yes, this 90-degree elbow fitting is designed to connect ORFS and metric systems.

Answer by: Customer Support on Jan 20, 2026, 7:45 PM

Got a metric port on my manifold block that's M18 x 1.5 and I need to turn 90 degrees into an ORFS line, this the right fitting for that?

Question by: Todd F on Dec 12, 2025, 10:38 AM

That's what this one's built for. The metric side is male M18 x 1.5 and the ORFS side is male 3/8" with an 11/16-16 UN thread. The adjustable feature on the metric end lets you clock the elbow to the angle you need before locking it down, so routing the line in tight spaces is a lot easier. Steel construction handles the demands of standard hydraulic hydraulic connections without issue.

Answer by: Customer Support on Dec 14, 2025, 6:09 AM
