Din X Male Mm Taper Complete

Adaptall Shape Straight	Side 1 Callout M10 X 1.0	Side 1 Gender M	Side 1 Size LL06	Side 1 Type Din Tube	Side 2 Callout M10 X 1.0	Side 2 Gender M	Side 2 Size 10mm	Side 2 Type Metric Taper	Brand Adaptall America	Brand Adaptall	Pack Size 1.00	UOM EA	Supplier Part Number 5068LLT-06-10X1C	Product Weight 0.03 lbs

Product Questions & Answers 1

Product Questions & Answers

Got a DIN tube connection on one side and a metric taper port on the other, is this the fitting that bridges those two?

Question by: Wade P on Mar 26, 2026, 11:54 AM

Yeah, that's exactly what this one does. One side is a DIN tube connection sized at LL06 with M10 x 1.0 male threads, and the other side is a metric taper at 10mm, also M10 x 1.0 male. Both sides are male, so you'd need the appropriate female ports on your lines or components to mate up with it. Straight configuration means no bends or angles, just a clean inline connection between those two thread types.

Answer by: Customer Support on Mar 28, 2026, 11:29 AM
