Split Flange Code 61

Certifications SAE J1176	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	End Type 1 Flanged	End Type 2 Line/Hose/Tube	Features Dura-Kote plating for superior corrosion resistance\|Innovative design to deliver performance and maximum uptime\|System engineered to extend hose assembly life	Hose Dash Size -12	ICC Hose Fittings	Item Type Fitting Assembly	Language English	Net Pack Quantity Units EA	NMFC 50	Product Material Carbon Steel	Product Width 2	Sub Brand None	Supplier Part Number 4S20FL12	Product Weight 1.04 lbs

Product Questions & Answers 2

Product Questions & Answers

Hey, will this flange fitting work with a standard hydraulic hose?

Question by: Lyle E on Mar 15, 2026, 12:07 PM

This Eaton Aeroquip fitting is designed for use with 4-wire spiral hydraulic hoses.

Answer by: Customer Support on Mar 16, 2026, 7:44 PM

fitting says "split flange code 61" -- does that mean it comes as two pieces that bolt together around the hose end, or is it a one-piece crimp setup?

Question by: Wayne H on Aug 1, 2025, 9:13 AM

Split flange fittings work with two separate flange halves that clamp around a flange head, then bolt to a matching flat-face port. The crimp end of this fitting attaches permanently to the hose during assembly. So you get a crimped connection on the hose side and a bolted split flange connection on the port side. The SKU 4S20FL12 is built for 4-wire spiral hose at a -12 dash size, so make sure your hose matches that before ordering.

Answer by: Customer Support on Aug 2, 2025, 7:14 PM
