Alternate Part NumberMI-00325732, Alternate Part Number MINO-00015X01054
Certifications
SAE J1176
Drop Dimension
2.13
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
End Type 1
Flanged
End Type 2
Line/Hose/Tube
Features
Dura-Kote plating for superior corrosion resistance|Innovative design to deliver performance and maximum uptime|System engineered to extend hose assembly life
does this fitting need a mandrel to put it on, or can you just press it straight onto the hose?
Question by: Hank S on Sep 30, 2025, 5:58 PM
No mandrel required for this one. It's a permanent fitting, so the installation process doesn't call for that extra tooling step. The 4S design handles the connection without it, which tends to make assembly go a bit smoother on the floor.
Answer by: Customer Support on Oct 1, 2025, 8:21 PM
trying to swap out an old Aeroquip fitting, is 4S12FLB8 the right part number for this one?
Question by: Hank T on Jun 30, 2025, 4:13 PM
For replacement matching, the supplier part number on this fitting is 4S12FLB8, and it also crosses to MI-00325732 and MINO-00015X01054.
Answer by: Customer Support on Jul 1, 2025, 6:16 PM
Is this fitting good for high-pressure applications, or should I be looking at something else?
Question by: Carl R on Jan 8, 2026, 6:59 PM
This fitting is made from carbon steel, offering good durability for various applications. It's certified to meet SAE J1176 standards, so it should hold up well, but make sure it's the right fit for your specific pressure requirements.
Answer by: Customer Support on Jan 9, 2026, 7:44 PM
