Danfoss / Eaton 2FPH350P12W350SVH24 DUAL Flow REGU 405AA00106A

Specifications

Application Harvesters, refuse haulers, mobile and industrial applications	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 350 L/min (92 USgpm)\|Perfect balance of pressure and flow\|Reliable, economical and compact	Flow Rate1 350 litre per minute	ICC SICV Flow Control Valves	Language English	Net Pack Quantity Units EA	Port Size 1 1/2”	Product Width 3	Style Adjustable Pressure Compensated, Flow Regulator	Sub Brand Vickers	Supplier Part Number 405AA00106A	Voltage 24 volt	Product Weight 61.00 lbs

Product Questions & Answers 2

Product Questions & Answers

What size ports does this regulator have? Need to make sure it matches my existing setup.

Question by: Freddie W on May 19, 2025, 7:39 PM

It comes with 1 1/2" ports.

Answer by: Customer Support on May 21, 2025, 6:42 AM

got a harvester running dual hydraulic circuits and been fighting pressure drop issues on the flow side. this valve rated to handle that kind of load steady, or is 350 bar more of a peak number?

Question by: Hugh A on Jul 30, 2025, 1:09 PM

350 bar (5000 psi) is the rated operating pressure for this valve, and the pressure-compensated design means flow stays consistent even when load pressure shifts. That compensation is the whole point of a flow regulator like this one. For a harvester running dual circuits, the single valve body handles both simultaneously, which cuts down on the number of components you'd otherwise need to manage two separate flow paths. At up to 350 L/min (92 USgpm) through 1.5-inch ports, it's built for exactly the kind of high-demand work you're describing.

Answer by: Customer Support on Aug 1, 2025, 9:28 AM
