35M Series Vane Motor, 115 Ring Size, 14 Tooth SAE C Splined Shaft, Outlet Port Connections In-line (C)

Application Elevator scraper drives, hydrostatic drives, auxiliary applications	Configuration 32	Design Code 20	Displacement 7.44	Displacement 7.44	Brand Danfoss (Power Solutions II LLC)	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features Reliable, efficient performance\|Long lasting\|Quiet operation	Port Location Port Connections In-line (C)	Ring Size 115	Ring Size 115	Seal Material Buna-N	Series 35M	Shaft 14 Tooth SAE C Splined	Shaft 14 Tooth SAE C Splined	Shaft Seals Single	Special Features None	Supplier Part Number 312062-3	Thru Drive No	Torque Rating 115 lb-in per 100 psi	Torque Rating 115 lb-in per 100 psi	Vane Function Type Motor	Alternate Part Numbers Alternate Part Number 35M115A11C20, Alternate Part Number C1BL63, Alternate Part Number F08020	Product Weight 65.00 lbs

Product Questions & Answers 3

Product Questions & Answers

Would this Eaton Vickers motor be alright for a elevator scraper drive?

Question by: Donna H on Feb 17, 2026, 6:04 PM

Given its listed applications, this 35M series vane motor can certainly handle elevator scraper drives.

Answer by: Customer Support on Feb 19, 2026, 3:47 PM

trying to swap out an old Eaton Vickers motor, is this one the 35M115A-11C20 model with the in-line ports?

Question by: Judy A on Apr 4, 2025, 3:15 PM

Match it up by the model number 35M115A-11C20 and the port location called out as in-line (C). It is also a single configuration 35M series vane motor with ring size 115, so those identifiers should line up with what you are replacing.

Answer by: Customer Support on Apr 5, 2025, 6:03 PM

Trying to match up a replacement for an old Vickers vane motor on an elevator scraper drive. The shaft on mine's got 14 teeth, SAE C spline, and the mounting flange is 2-bolt SAE C. This the right unit for that?

Question by: Brett K on Jul 1, 2025, 5:08 PM

For that configuration, yes, this one lines up. The 35M115A-11C20 runs a 14 tooth SAE C splined shaft and mounts on a 2-bolt SAE C flange, so the mechanical fit is there. Ports are 1-1/2 inch SAE 4-bolt flange, in-line configuration, with a 3/8 NPT drain in the rear cover. If your existing hydraulic connections matches that layout, you're in good shape for a direct swap.

Answer by: Customer Support on Jul 3, 2025, 8:43 AM

Similar Products

Part Number	Model Number	Shaft	Displacement	Ring Size	Torque Rating	Price	Buy Now
312062-3	35M115A-11C20	14 Tooth SAE C Splined	7.44	115	115 lb-in per 100 psi
312065-3	35M115A-1C20	1-1/4 Straight Keyed	7.44	115	115 lb-in per 100 psi
