BRASS 90DEG #10 MJIC X 3/4" M-PIPE 2501-10-12-B

Specifications

Brand Brennan Industries Inc	Brand Brennan Industries	Pack Size 1.00	UOM EA	Supplier Part Number 2501-10-12-B	Product Weight 0.46 lbs

Product Questions & Answers 3

Product Questions & Answers

trying to replace an elbow on a hose, is this one #10 male JIC on one side and 3/4 male pipe on the other?

Question by: Neil H on Feb 15, 2026, 7:52 AM

On the JIC side, it has a #10 male JIC 37 degree flare thread, 7/8-14 per SAE J514. The other end is a 3/4-14 male NPTF pipe thread per SAE J476, so it is a #10 MJIC x 3/4 inch M-pipe 90 degree elbow.

Answer by: Customer Support on Feb 16, 2026, 3:37 PM

what's the thread setup on this fitting, both ends? trying to figure out if it'll tie into my hydraulic line and a pipe port without needing an adapter in between

Question by: Larry R on Nov 4, 2025, 8:57 AM

One end is a #10 Male JIC with a 37-degree flare, sized at 7/8-14 threads, built to SAE J514. The other end is a 3/4-inch Male NPTF, running 3/4-14 threads to SAE J476. So you've got a JIC flare end going into your hydraulic hose connection and a tapered pipe thread end going into the port. No additional adapter needed as long as both your line and your port match those specs.

Answer by: Customer Support on Nov 6, 2025, 8:39 AM

What size pipe threads does this fitting have? Just want to make sure it'll fit what I'm working on.

Question by: Ray K on Apr 24, 2025, 7:52 PM

The pipe thread is 3/4-14, conforming to SAE J476 standards, which is a male NPTF (National Pipe Taper Fuel) type.

Answer by: Customer Support on Apr 26, 2025, 11:20 AM
